123Tune+-6-R-V-G

399.14

The 123\TUNE+-6-R-V-G replaces most 6 cyl. Lucas-distributors for engines in Great-British (hence ‘GB’) cars.

Description

123 Tune+-6-R-V-G

123MERCEDES-4-R-V

The 123\TUNE+-6-R-V-G replaces most 6 cyl. Lucas-distributors for engines in Great-British (hence ‘GB’) cars.

Please check if the distributor need a connection for a mechanical rev.counter, as a 123\TUNE+-6-R-V-G does not offer this.
123ignition is proud to announce the first fully programmable wireless Bluetooth 4.0 ignition! Control your 123\TUNE+ with your iOS/Android smartphone or tablet. The App makes it possible to adjust the ignition curve and shows an electronic dashboard.

Main features: REV-counter, Antitheft system by a PIN code, Bluetooth 4.0, Real-time tuning, Vacuum advance, Boost retard, Soft REV-limiter, etc.

SPECIFICATIONS
cylinders: 6
direction: CW/CCW
voltage: 4,0-15,0 Volts
range: 500 – 8000 rpm
temperature: -30 to 100 Celsius
coil: stock or High Energy coil, primary coil NOT below 1,0 ohm
dwell: constant current, fully autom.
time-out: after 1 second current is switched off
spark-bal.: better than 0,5 degr. crankshaft
vacuum: vacuum advance or boost retard, max. 20 degrees crankshaft
max.advance: 45 degr. crankshaft
curves: one programmable advance curve
Programmable: By iOS or Android app via Bluetooth 4.0
Rev limiter: Programmable soft rev limiter ( max 7900 rpm ), 60% of the sparks will cut off
wiring: red = +6V or +12V, black = ‘-‘ coil, blue = ground
123 ignitions pristine parts

123ignition has been active in the field of classic cars for more than 15 years and through this became a respected brand. The company started in 1992 and from 2001 fully focused on electronic ignition systems. The first prototype ignition was born out of passion a couple of years before. A project was started to provide an electronic ignition for a Citroen 2CV. This turned out to be such a great success that the project was turned into a product. Meanwhile, the assortment expanded more and more, and we can now offer a suitable product for many classic cars.
