Description
The 123ALFA-6-R-V
The 123ALFA-6-R-V is especially designed for the Alfa-2600.
This unit supports vacuum advance.The unit offers a maximum total of 16 advance-curves to be selected by the end-user.
Please take a look in the table below for available advance curves.
With vacuam advance
| advance starts | max. advance | vac. adv. starts | max. vac. adv. | |||||
|---|---|---|---|---|---|---|---|---|
| curve | [rpm crankshaft] | [rpm/ | degr. crankshaft] | [mmHg] | [mmHg/ | degr.] | replaces | remark |
| 0 | 0500 | 5000 | 40,0 | 100 | 200 | 8,5 | BOSCH 0 231 111 034 | MARELLI S93A ALFA-2600 |
| 1 | 1000 | 3600 | 17,0 | 100 | 300 | 10,0 | – | 2000/6,5 |
| 2 | 1000 | 3000 | 17,0 | 100 | 300 | 10,0 | – | 2000/8,4 |
| 3 | 1000 | 2500 | 17,0 | 100 | 300 | 10,0 | – | 2000/11,0 |
| 4 | 1000 | 4500 | 20,0 | 100 | 300 | 10,0 | – | 2000/6,0 |
| 5 | 1000 | 4500 | 20,0 | 100 | 300 | 10,0 | – | 2000/8,0 |
| 6 | 1000 | 4500 | 20,0 | 100 | 300 | 10,0 | – | 2000/10,0 |
| 7 | 1000 | 4500 | 20,0 | 100 | 300 | 10,0 | – | 2000/12,0 |
| 8 | 1000 | 4500 | 23,0 | 100 | 300 | 12,0 | – | 2000/6,5 |
| 9 | 1000 | 4500 | 23,0 | 100 | 300 | 12,0 | – | 2000/9,0 |
| A | 1000 | 4500 | 23,0 | 100 | 300 | 12,0 | – | 2000/11,0 |
| B | 1000 | 4500 | 23,0 | 100 | 300 | 12,0 | – | 2000/13,0 |
| C | 1000 | 4500 | 26,0 | 100 | 300 | 14,0 | – | 2000/7,5 |
| D | 1000 | 4500 | 26,0 | 100 | 300 | 14,0 | – | 2000/10,0 |
| E | 1000 | 4500 | 26,0 | 100 | 300 | 14,0 | – | 2000/12,0 |
| F | 1000 | 4500 | 26,0 | 100 | 300 | 14,0 | – | 2000/14,0 |
